Summary
The horizontal dry ball mill is the latest development of the new generation of dry ball mill. It is a new type of dry ball mill. It is the independent innovation and overcome many difficulties.
It is the best in the dry grinding equipment. It is the best choice for the dry ball milling of the material. Compared with the similar products abroad, its price is low, the quality is good, the effect is good, and it is more in line with the requirements of the user.

Main features ：
1 The equipment can not only discharge intermittently, but also make continuous discharge.
2 The granularity of materials can be controlled freely according to users' requirements.
3 With the moving air and animal material discharged, the material is discharged very cleanly, and the discharging speed is fast without dead angle.
4 Because of the cooling of the air, constant temperature is maintained during ball milling.
5 The grinding efficiency is high, which is 30% higher than that of the ordinary ball mill.
6 The equipment not only saves energy and reduces consumption, but also is beneficial to environmental protection.
7 The equipment has good controllability, easy operation and low failure rate.

Engineering data

Type	Volume	φD	L	Motor	Speed	Inlet
WSM-60	60L	φ420	420	0.75-1.1	46	180
WSM-100	100L	φ500	520	1.1-1.5	40	180
WSM-200	200L	φ650	630	2.2-3.7	35	180
WSM-300	300L	φ720	750	5.5-7.5	31	180
WSM-500	500L	φ870	870	3.7-5.5	28	230
WSM-800	800L	φ1010	1010	5.5-11	28	230
WSM-1000	1000L	φ1090	1090	7.5-15	21	300
WSM-1500	1500L	φ1250	1250	11-18.5	18	400
WSM-2000	2000L	φ1370	1370	15-37	18	400
WSM-3000	3000L	φ1570	1570	18.5-55	16	500
WSM-5000	5000L	φ1860	1860	37-75	16	500
